UK User Manual CONTENTS. 4. Brief description of phone functions Description of basic operations Overview of available functions 19

Transkript

1

2 - 2 -

3 UK User Manual CONTENTS 1. Safety precautions 4 2. Overview of the phone 5 3. Getting started 6 4. Brief description of phone functions Description of basic operations Overview of available functions Accessories Common faults Technical specifications 48 Contents of the packing: Phone, Battery, Travel Charger, USB data cable, User Guide, 2 second Battery (Optional Accessory), Battery Charging Stand (Optional Accessory), Headset (Optional Accessory), second Stylus (Optional Accessory) - 3 -

4 1. Safety precautions Please read the following instructions before using your mobile phone to ensure safe and efficient use. Do not use near chemical plants, petrol stations, flammable liquid storage or similar areas where an electrical discharge may cause a fire. Keep the phone out of the reach of children. Use the hands free kit for calls while driving. Stop the car on the roadside when calling. Do not use the phone while driving at high speed. Do not use the phone in an aircraft. Check if the function of the automatic switch on is switched off or if both SIM cards are switched off before boarding an aircraft. Do not use in hospitals or health care facilities. It may interfere with medical devices and endanger the health of patients. It may interfere with the function of medical devices, especially pacemakers, hearing aids or similar electronic devices. Non-original devices used in connection with the phone are not covered by the guarantee. Do not tamper with the device in any way. Should this product fail to operate properly, please contact our authorized service. Do not charge the phone without a battery. Please switch off the phone before removing the battery. Charge the phone in areas with sufficient air circulation and heat removal, away from explosive and highly flammable materials. Keep away from objects sensitive to magnetic fields, e.g. credit cards. Your phone is not water-resistant. Keep it dry. Do not use the phone in areas with extreme temperatures. Keep away from direct sunlight or areas with high humidity. Do not use a wet cloth or strong detergents to clean the surface of the phone. Your phone enables you to record photos and sounds. Use these functions according to the general regulations and restrictions. Taking photos and recording sounds without approval can be penalized by law or regulations. Protect the device from dropping or knocking. This type of handling can damage the surface and technical components inside. Dispose of used batteries according to guidelines and instructions for the safe disposal of this kind of waste. Notice: Our company does not assume any responsibility for any loss or damage relating to this device if not used in accordance with the abovementioned recommendations. In regard to ongoing device development and improvements, the text of this User Guide can be modified. Our company reserves the right to make changes in the text of this User Guide without prior notice

5 2. Overview of the phone Your device has 21 keys on the keypad, three side keys and an information display. It has a Vibration motor, Headset, Power/USB data cable, Universal port, Connector of memory card (microsd/t-flash) and Stylus. Overview of the phone: 1. Eyelet for strap 2. Camera lens 3. Slot for microsd card 4. Self-portrait mirror 5. Lock of back cover 6. Volume key 7. Charger/Headset/USB connector 8. Loudspeaker 9. On/Off/End key 10. LCD display 11. Cursor keys 12. Multifunctional keys 13. Call key for SIM1 card 14. Call key for SIM2 card 15. Numeric keypad 16. Microphone (in the lower part) 17. Camera key 18. Stylus Note: Do not press the LCD display forcably. Doing this may cause irreversible damage. We recommend you to use a plastic film which is readily available to protect the display

6 3. Getting started Insert SIM card If you want to have more phone numbers you can have them from one or two mobile operators. Each phone number is represented by one SIM card (Subscriber Identity Module). You can make use of all functions and services of your mobile phone with these two cards. All the important data and personal information including a PIN code (personal identification number), your list of contacts, short text messages and other system services, are stored on these cards. Notice: Protect SIM cards from bending or scratches. Protect them from static electricity, dust or water. If you lose your card, immediately contact your mobile operator with a request for help. Switch off the phone before inserting the SIM card. Insert SIM cards from the backside of the device. Note: The SIM card is a small object. Keep it out of the reach of children. If swallowed, it can cause injury or serious health-problems

7 Use of the microsd card Your telephone may require more memory for the efficient operation of some functions, than with the standard equipment. Memory expansion is possible through the memory card (microsd card). Insert a microsd card: Remove the plastic cover of the microsd card slot and insert the card into the device. The text Card inserted appears on the display. Close the plastic cover. Remove the microsd card: Scroll to the menu Explorer, find the item Memory card, select Options and Remove card. Then remove the plastic cover and press the card slightly in. The card releases and the text Card removed appears on the display. Close the plastic cover. Note: The microsd card is a small object. Keep it out of the reach of children. If swallowed, it can cause injury or serious health-problems

8 Inserting the battery Use only original batteries and accessories included in delivery. Remove the battery from the phone if the battery has not been used for a prolonged period. Insert the battery according to this diagram: Note: Be careful when inserting the battery, as the contacts can be damaged

9 Charging the battery The new battery achieves its optimal capacity after a few full charge and discharge cycles. Charge only, if the battery is completely discharged. Overcharging may shorten its lifetime. Unplug the charger from the electrical plug and then disconnect from the phone, when fully charged. Remove the plastic cover and connect the charger to the upper connector. The charging indicator appears on the display, when charging. The symbol of the battery charge level is completely filled, when the charging process is finished. It warms up during the charging process. This is a normal effect. Use of the battery The operating time of the battery is influenced by several factors, e.g. configuration of wireless network, signal strength, normal temperature of the mobile phone, used functions and settings, accessories or mode of audio and data services or other services. You achieve the optimal length of operating activity with the fully charged battery, if you follow these instructions: New or older batteries which were not used for a prolonged period need relatively longer time till they are fully charged. During the charging process, the temperature of the battery should be at room temperature or a little bit higher. It is normal, that the longer the operating time is, the longer the charging time is. If the operating time after a full recharge is reduced and the time needed for a full recharge grows, it is probably necessary to buy a new, original battery. Use of improper accessories with the phone may cause, not only damage to the device, but also to your health. If the battery has not been used for a prolonged period, it can take some time till current data appear on the display. Please be patient. Note: To ensure your safety and to protect the environment, please dispose of old batteries as permitted by the law. Warning: Any short-circuit in the device or battery may cause explosion, fire or injury

10 Use of the stylus The stylus is an important part of the mobile phone which allows the user to use its functions. The length of the stylus is adjustable. If you do not want to use the stylus for the moment, shorten it first to the minimum length and then insert it into the slot in the lower part of the phone. Insert the stylus in a way shown in the following diagram. Note: The stylus card is a small object. Keep it out of the reach of children. If swallowed, it can cause injury or serious health-problems!

11 PIN for the SIM1 card PIN: It is a personal identification code which helps to protect your SIM card against unauthorized use. If the card protection with the PIN code is activated, the text Enter PIN for SIM1: appears on the display after you insert the SIM1 card and switch on the phone. When you enter the PIN, the characters of star ( * ) appear on the display. You get the PIN from the mobile operator. PIN2: It is a personal identification code which is required for some special functions, e.g. charges in the mobile operator network, etc. PUK and PUK2 (8 digits): Is the PIN code blocked (e.g. if the code was entered incorrectly many times), it is required to change the PIN code. In this case it is required to enter the PUK code. The PUK2 code is required to change the PIN2 code. If the codes are not supplied with your SIM card, contact the local service of your mobile operator for the codes. Warning: If the PIN is entered incorrectly three times, the SIM card is automatically barred. Contact your mobile operator for help. In case you incorrectly unlock the SIM card, the card may be permanently damaged. PIN for the SIM2 card PIN: It is a personal identification code which helps to protect your SIM card against unauthorized use. If the card protection with the PIN code is activated, the text Enter PIN for SIM2: appears on the display after you insert the SIM2 card and switch on the phone. When you enter the PIN, the characters of star ( * ) appear on the display. You get the PIN from the mobile operator. PIN2: It is a personal identification code which is required for some special functions, e.g. charges in the mobile operator network, etc. PUK and PUK2 (8 digits): Is the PIN code blocked (e.g. if the code was entered incorrectly many times), it is required to change the PIN code. In this case it is required to enter the PUK code. The PUK2 code is required to change the PIN2 code. If the codes are not supplied with your SIM card, contact the local service of your mobile operator for the codes. Warning: If the PIN is entered incorrectly three times, the SIM card is automatically barred. Contact your mobile operator for help. In case you incorrectly unlock the SIM card, the card may be permanently damaged

12 4. Brief description of phone functions Call key for SIM 1/SIM 2 card It is used for calls from SIM1/SIM2 card (if you enter the phone number of called person or if the phone number was saved in the list of contacts). With this key you can answer incoming calls for SIM1/SIM2. To access the information about last calls (incoming, missed, outgoing), press this key in the initial mode. The device saves information about the last 40 calls at most. If you press this key twice in the initial mode, the device dials the last phone number. On/Off/End key While pressing this key, you finish a call or pass to the initial mode of the device. If you press and hold this key in the initial mode for 3 seconds, the device switches off. If you press and hold this key again, you switch on the device. Keypad lock If the device is not used for a prolonged period, the keys are locked automatically (if set up). To unlock them, press the red key for On/Off and then click on the display with the stylus or press * key. If you want to lock the keys by hand, press the red key for On/Off and then *. If you have an incoming call, the keys unlock. When you end, they lock automatically again. Alphanumeric keys If the phone number input or edit mode through the display is switched on, enter numbers and characters briefly one after another. If you press and hold some of 1-9 keys for longer than 2 seconds, the speed dialling number will be called. Note: If you press and hold the 1 key in the initial mode, your voice mailbox number in the centre of voice messages will be called. It is usually used as a speed dialling number. The number of the centre of voice messages is entered in the phone according to particular mobile operator. The * and # keys have different functions in different operating modes of the device: If the phone number input mode through the display is switched on, you switch on or off the silent mode when you press and hold the # key. If you press and hold the * key on the keypad, the P, +, W or * characters will be input. The P and W characters are used for simplification of calls through Direct Dial-In. The + character is used for international calls. Note: The W and P characters are different. The P character sends DTMF signal after 3 seconds period, but the W character shows a display with a question, if the user wants to send DTMF signals

13 Side keys Table with description of side keys functions: Camera Press and hold/briefly press Press and hold MP3 reproduction Briefly press Turn the volume up Press and hold Briefly press Turning up the volume of MP3 Turning up the volume of MP3 Turn the volume down Press and hold Briefly press Turning down the volume of MP3 Turning down the volume of MP3 Interface for MP4 reproduction Save an image in the interface Save an image in the interface Turning up the volume of MP4 Turning up the volume of MP4 Turning down the volume of MP4 Turning down the volume of MP Incoming call During call In the initial mode Camera switch on and taking pictures Camera switch on Turning up the volume of ringing Turning up the volume of ringing Switch off ringing Switch off ringing Turning up the volume of listening Turning up the volume of listening Turning down the volume of listening Turning down the volume of listening Turning up the volume by pressing a key Turning up the volume by pressing a key Turning down the volume by pressing a key Turning down the volume by pressing a key

14 Ikons Signal SIM1 Signal SIM2 Alarm Message for SIM1 Message for SIM2 Battery charge level Ringing this icon can be different according to the ring tone and can also be displayed with the following symbols: Vibrating alert and then ringing Vibrating alert and ringing Vibrating alert only Missed call Keypad lock is active Received mail of the service (e.g. MMS) GPRS is active Bluetooth is active and enables other devices to find the phone. Blinking means the status change. Bluetooth is active but the device can not be found by other devices. Phone is connecting to the headset Languages and the set of used characters Your phone supports input of Czech/English characters. Particular functions depend on the chosen set of characters. Indication possibilities of incoming calls Your phone is equipped with a vibration motor and ringing which allows the following indication ways of incoming calls: Ringing Vibrating alert only Vibrating alert and then ringing Vibrating alert and ringing Services Services represent a set of available tools on the used SIM card (e.g. SIM ToolKit). Your phone supports these tools only on the SIM1 card. Particular items in the menu depend on the possibilities of used network. If the network supports these functions, the phone takes them over automatically

15 Ringing profiles Ringing profiles are in this phone divided in Friend, Family, VIP, Work and Others. You can assign a special ring tone and picture to each group. Explication of some terms Local calls The easiest way to make a call is to enter the phone number with the stylus on the display or to press it on the keypad and then press the call key for SIM1 or SIM2. If you want to modify the entered phone number, press Delete. The entered character will be deleted and you can replace it with another. After the call was connected, the information about the calling process appears on the display. To terminate the call, press the red key. Phone number dialling for local calls: You can enter only 8-digit code or you enter before this code also a country calling code (e.g for CZ). International calls To make an international call, hold the * key until the + character for the international calls is displayed. Enter then a country calling code (e.g. +49 for Germany). After you enter a country calling code, enter the whole phone number in an international form. Calling process: + country calling code + the whole phone number with the prefix of the region + call key for SIM1/ SIM2. Calling a line in a Private Branch Exchange To call some phone numbers, you may have to dial a phone number of a Private Branch Exchange and then the number of the particular line. In this case, enter the phone number of a Private Branch Exchange, enter a gap (by holding the * key on the display there appears the P character) and then enter the number of the particular line. The phone dials the first part of the entered number till the P character and after 3-second pause finishes the call by dialling the number of the particular line. Calling process to a fixed phone line: enter the phone number + P + the number of the line + call key for SIM1/ SIM2. Emergency call In every country with the GSM network and in a place with signal coverage (you can check the strength of the receiving signal in the left corner of the display), you shall have the possibility to make emergency calls free of charge. If your mobile operator does not offer roaming services in the particular country, the text SOS restriction of calls, only emergency calls possible - appears on the display. This service is available in the places with signal coverage of any mobile operator and you can use it also in case the phone is without any SIM card. * The phone number 112 is usually used in many countries for emergency calls regardless of the mobile operator. Before you travel abroad, you should ask your home mobile operator and check the emergency phone number and its availability! IMEI (International Mobile Equipment Identification) Switch the phone off and remove the battery. You may find a printed code under the battery. This number is also saved in the memory of the device. You can display it if you enter *#06#

16 5. Description of basic operations Switching the device on To switch the device on, press the red key. If the SIM card and the phone are not protected with a pass code the starting menu appears on the display and then the automatic search for the signal starts. After the phone register in the mobile network, the operator s name or code display. If the text Insert the SIM card! appears on the display, switch the phone off and check if the SIM card was inserted in the right way. After you insert the SIM card, the phone checks the possibility of its use and displays the texts in following chronology: 1. Enter the PIN for SIM1 card: in case, that the protection with PIN code for SIM1 is setup. 2. Enter the code of the phone: in case, that the protection of the phone is setup (predefined code is 1122). 3. No services information about an unsuccessful attempt to register in the network. Only emergency calls with the phone number 112 or other numbers are available. 4. SOS the phone is registered in the network of another operator; you can only call the phone number 112 or the number of another emergency service. 5. Search search for an appropriate mobile network. The second SIM card can be automatically used for searching the network, if the starting sequence, after you switch the phone on, is setup for Only SIM2 card. Following texts can appear on the display, if setup: 6. Enter the PIN for SIM2 card: in case, that the protection with PIN code for SIM2 is setup. 7. No services information about an unsuccessful attempt to register in the network. Only emergency calls with the phone number 112 or other numbers are available. 8. SOS - e phone is registered in the network of another operator; you can only call the phone number 112 or the number of another emergency service. 9. Search search for appropriate mobile network. Note: If you forgot the PIN code of first or second SIM card, contact the particular mobile operator. Switching the device off To switch the phone off, press and hold the red key until the display is turned off. The SIM1 and SIM2 cards will be disconnected simultaneously. Never switch the device off by removing the battery. Doing this may cause damage to the SIM cards. Speed options in the initial mode In the lower part of the display there are 5 icons which are for speed options of functions. There are: starting menu, list of contacts, messages, camera and picture browser. Then you can configure what should be activated after pressing cursor keys

17 Calls Enter the phone number which you want to call in the initial mode. You delete the wrong character with the key Delete. To dial the phone number, press the call key for SIM1/SIM2 card. To terminate the call, press the key Cancel. With the key Delete, you interrupt the call. Information about the call length is displayed during the call. Call of phone number that you have saved in contacts: find in contacts the phone number and press the call key for SIM1/SIM2 card. Repeated dial of last called number: To access 90 last phone numbers (incoming, missed or outgoing calls), press the call key for SIM1/SIM2 card in the initial mode. Find the particular phone number in the list and press the call key. Adjusting the volume To adjust the volume on a call, press the volume key on the side of the phone. Answering a call If you are called by somebody, the phone can announce it in three different ways: only ringing or vibrating alert, eventually simultaneous ringing and vibrating alert or first vibrating alert and then ringing. To answer a call, press the call key for SIM1/SIM2 card. To reject a call, press the key Cancel or press the key Reject on the right side of the display. If the program of caller identification is activated, his phone number appears on the display. If you saved this phone number in list of contacts, the caller name appears instead of the phone number. If the call is for the number of SIM1 card, SIM1 appears before the displayed number. If the call is for the number of SIM2 card, SIM2 appears before the displayed number. Speed display of messages for SIM1 To display messages sent to the number of SIM1, press New SMS SIM1 in the initial mode of the device. Speed display of messages for SIM2 To display messages sent to the number of SIM2, press New SMS SIM2 in the initial mode of the device. Speed display of missed calls To display the list of missed calls, press Missed calls on the display

18 Speed dialling Your phone enables you to define 8 speed dialling options. Each of them represents one phone number (more information in the part List of contacts ). Whenever you want to use one of these speed dialling options, press and hold one of the 2-9 key. The 1 key is reserved for calls to the voice mailbox. First you have to set it up. Note: To initiate the function of speed dialling, click on the particular number with the stylus on the display or press the particular key for more than 2 seconds. The function of speed dialling is not active, if you do not assign any digit to a phone number in the menu Settings. DTMF signal sending If you use the function of DTMF signal sending while you dial the phone number, the entered digits and * and # characters will be sent with DTMF signal. It is not possible to call the intern line with Direct Dial-In, if this function is not switched on. Speed display of SMS After receiving of SMS, the icon which means that an unread message was saved, appears on the display. To read it, press Read. Missed calls A missed call is indicated with an icon on the display. To have more information about this call, press Read. Voice mailbox calls Your phone enables you to divert your incoming calls to the voice mailbox. You receive a message after the message of the caller has been saved. (To use this service, enter first the number of the voice messages centre.)

19 6. Overview of available functions Contacts management List of contacts Your phone is equipped with a list of contacts where you can save the following information: three phone numbers (mobile, home, office), name of the company, address, fax, photographs, sound, group of callers (without allocation, friends, family, VIP, work, another). On the SIM card, you can save only name and phone number. The phone enables you to save up to 1000 contacts. The phone enables speed dialling of phone numbers. If you assign a digit to a phone number, press and hold one of the digit key for more than 2 seconds. You can save up to 14 characters in the list of contacts memory if you use the Czech diacritic and up to 30 characters if you use ASCII characters. Speed Search Enter the first characters on the cursor position to search for the word. The phone searches for the first most similar contact which corresponds to the entered characters. E.g. to search for Novak, enter n. Search for an entry Enter the desired text. The phone searches for the entry in the list of contacts which most corresponds to the text. Add new contact To SIM1/SIM2: You can save an entry which contains first name, name and phone number. To the phone memory : You can save an entry which contains first name, name, name of the company, mobile phone number, home phone number and office phone number, address and fax. You can assign to the entry a picture/photo, ring tone and put it into a selected group of callers. Note: If you assign to the entry both a picture/photo and a ring tone, only the picture/photo will be active. Copy all To copy entries from SIM1 in the phone, from the phone to the SIM1, from SIM2 in the phone or from the phone to the SIM2. Delete To delete all the entries from SIM1, SIM2 and the phone or to delete desired entries gradually

20 Groups of callers You can attach to each of five groups a name, a ring tone, a picture and the list of its members. Extra phone numbers To enter your own phone number, the number of service support and the number for emergency calls (the function for calls to the service support and emergency calls has to be supported by the SIM card consult your mobile operator about details). Settings Memory status: To display the memory capacity of SIM1, SIM2 and phone. The information displays in the format: utilized capacity/ total capacity. Preferred memory: To choose automatically selected memory for new data. List of contacts field: To select items for saving in the list of contacts and to set up their display when they are entered. My business card: To edit and send the personal business card. Picture of a caller To attach a picture/photo to an entry which displays during the incoming call. Ring tone of a caller To attach an individual ring tone to an entry. Messaging SMS to SIM1 / SMS to SIM2 Sending and receiving SMS is a kind of service which is provided in the mobile network. To use this function, you have to connect to this network. Both of your SIM cards support the function of text messages sending. The message is first sent to the centre where it is then passed on to the recipient (user of GMS network). If the phone of the recipient is not switched on or he can not receive the message (full memory), the message will be temporarily saved and repeated attempts to deliver it will be made. The length of message validity is defined by both the user and the mobile operator. Your phone supports the sending of longer text messages. (Longer messages are sent as a series of two or more messages.) They will be charged accordingly. If the capacity for saving messages is full, the symbol of message will flash in the upper part of the display. The messages received to SIM1 and SIM2 are saved separately. The text on the display announces if the capacity of SIM1 card or SIM2 card is full. The phone can not receive SMS to the particular phone number until the old messages are deleted and the capacity released. The received message is displayed with a announcement (if this function set up). Note: While sending the message via SMS service, the announcement Sent means, that the message was sent from the phone to the SMS centre. But it does not mean that the message was received by the recipient. To get more information about SMS services and possibilities, ask your mobile operator

21 Write text It is possible to write text messages in this menu. Every message can have up to 612 alphanumeric characters (if you use the Czech diacritic, then 268). While writing, press # and you change the way of entering characters. To enter the symbols, press the * key. You can delete the last character when you press Delete. To delete all entered characters, press and hold Delete. To come back to the initial mode, press Back. While sending the message, you can select Done. This option depends on the card which you want to use for sending the message. Function Description Use template To write a text you can select one of 10 templates. Enter object You can enter an object in the message. You can select it from these options Picture, My picture, Predefined animation, My animation, Melody, My melody or Predefined sound. Text format Settings: Text size, Text style, Align, New paragraph. Method of text input To enter messages, you can use one of these methods: ABC, abc, Numbers, Multitap CZ or Multitap cz. Handwriting If you enter characters by handwriting, you can set up the following parameters: Handwriting style, Speed of pen and Colour of pen. Note: You can enter pictures into messages, if the mobile operator network supports this function. Only phones which are equipped with a function for displaying picture messages can receive these messages. Incoming You can browse delivered messages in the folder Incoming. Reply with SIM1 (or SIM2): To create a reply to delivered message. Delete: To delete of marked text message. Edit: To edit a selected message and send it. Forward: To forward a delivered message to other recipients. Copy to SIM card: This option enables you to copy a message to the SIM card, if the SMS is saved in the phone memory. Move in SIM card: This option enables you to move a message in the SIM card, if the SMS is saved in the phone memory. Delete all: To delete all messages from the SIM card. Copy all: To copy all messages from the SIM card/phone

22 Move all: To move all messages from the SIM card/phone. Use phone number: To save or dial a phone number from which the message was sent. Use URL: If URL is in the message, this address will be used. Save objects: To save an object or ring tone which was a part of the message. Sent When you send a message, select Save and send to. The message will be saved to the folder Sent and then send. You can save the written message directly to the folder Sent in the phone. In this case this message will not have a particular phone number (it will be denominated as No phone number ). Messages which were not possible to send are saved to the folder Sent as well. In this folder, you can edit, resend messages, delete particular items or all messages, or you can use phone numbers of senders/recipients for making a call. Drafts This folder is for drafts. You can use the following functions: Send to Edit Delete Copy to SIM card/phone Move to SIM card/phone Delete all Copy all Move all Use phone number Use URL False Messages with false content (number or heading) are saved to this folder. It is advantageous for identification of sender and phone number. Templates To edit and delete templates

23 Message settings In this menu, you can set up some parameters for short text messages. Profile setting: If you want to use SMS services, you have to enter the number of the message centre in this item. Note: The mobile operator provides the number of the message centre. Common settings Delivery report: The sender gets from the network the information about delivery of sent messages with the delivery time. Same SMS centre for reply: If you want that the receiver replies via the same message centre, tick this option - this function has to be supported by the message centre. Memory status: To display the level of memory capacity on the SIM card or in the phone. Preferred Disposal: To set up the preferred place for saving messages (SIM card or phone). Preferred Transfer: You can select if you prefer to transfer via GPRS or GSM, eventually if you want to use only GPRS or GSM. The manufacturer has set GSM in preference. (This parameter can be used only for messages saved in the phone.) MMS (only for SIM1) Multimedia messages contain characters, voice and image. Your phone supports MMS transfer with a maximal size of 100KB. If the message exceeds this limit, the device can not receive it. If the MMS contains a picture, the phone edits it automatically so that it can be displayed on the display. Note: You can use this function only, if the mobile operator network supports it. Only devices which are equipped with the function for displaying multimedia or messages can receive multimedia messages. Write message For Add phone number enter the number of the recipient. Add enter the address. Copy Add phone number enter the number of the recipient. Add enter the address. Blind carbon copy Add phone number enter the number of the recipient. Add enter the address

24 Subject: enter the text which describes the MMS. Edit contents You can use the following functions, to edit the message: Done: to finish MMS editing. Method of entry: to select the method for message entry. Add picture: to add a picture. Add sound: to add sound file. Add attachment: to add attachment. Enter new page: to enter a new page. Preview: to view the MMS with used effects, before sending it. Timing of pages: to edit the length of MMS content displaying and timing. Incoming You can browse delivered MMS in the folder Incoming and you can use the following functions: View: to view the MMS with picture, sound or attachment. Proprieties: to view the information about MMS. Reply to: to reply to the sender. Reply to all: if you received a message which was sent to many recipients, you can send your reply to all of them. Forward: to forward the MMS to another recipient. Delete: to delete a selected MMS. Delete all: to delete all received messages. Use phone number: to save or dial the phone number of the message sender. Sent To view saved MMS, you can use the following functions: Proprieties Send to Delete Delete all Use phone number

25 Drafts For saved drafts of MMS, you can use the following functions: View Proprieties Send to Edit Delete Delete all Use phone number Templates When writing messages, you can use several templates. Message settings In this menu, you can set up some parameters for multimedia messages. Create Mode for creating: to options are available: Free and Limited. Change size: you can select from possibilities 160*120, 320*240, 640*480 and OFF. You can switch the function off (OFF). Automatic signature: to switch on/off the function of automatic entry of predefined text. Send to Validity: to select the length of time, for which the MMS shall be available for the recipient in the message centre: 1 hour, 12 hours, 1 day, 1 week, Maximum. Delivery report: ON/OFF Read reply: ON/OFF Priority: you can select Normal, High or Low. Timing of pages: to set up the interval between slides in a multimedia message. The default time is 5 seconds. Maximum length of interval is 60 seconds. Delivery time: you have these options: Immediately, Till 1 hour, Till 12 hours, Till 24 hours. Receive

26 Home network: Delay, Immediately, Restricted. Roaming: As home, Delay, Restricted. Read reply: On request, Sent to, No send. Delivery report: ON/OFF Filter Anonymous sender: Allow, Reject. Maximum size (KB): maximum size of a delivered message is 100KB. Publicity: Allow, Reject. Server profile Activate profile Edit profile Rename profile: to change name of profile. Homepage: to edit the homepage address of the access point of MMS services provider. Data account: to enter account in the particular network. Type of connection: to set up the type of connection. User name: to edit the user name. Password: to edit the access password. Memory status: to view utilized, total and free capacity of memory. Server of voice mailbox SIM1 Voice mailbox is a service provided in the mobile network. It is possible that you have to ask the mobile operator for its activation. The mobile operator provides you with more information about the number of the voice mailbox centre and services provided. Edit: to edit and delete entered phone number of the voice mailbox centre. You have to confirm the change made by pressing a key. Connect to the voice mailbox: to dial the number of the voice mailbox with saved messages. If you have two phone numbers, each of them can have its own number of the voice mailbox. Note: If the device is in the initial mode and you have the number of the voice mailbox set, you will be connected with it when pressing 1 key. Set up calls to the appropriate voice mailbox for SIM1. After connecting you will have access to messages saved for this phone number

27 Server of voice mailbox SIM2 Voice mailbox is a service provided in the mobile network. It is possible that you have to ask the mobile operator for its activation. The mobile operator provides you with more information about the number of the voice mailbox centre and services provided. Edit: to edit and delete entered phone number of the voice mailbox centre. You have to confirm the change made by pressing a key. Connect to the voice mailbox: to dial the number of the voice mailbox with saved messages. If you have two phone numbers, each of them can have its own number of the voice mailbox. Note: If the device is in the initial mode and you have the number of voice mailbox set, you will be connected with it when pressing 1 key. Set up calls to the appropriate voice mailbox for SIM2. After connecting, you will have access to messages saved for this phone number. Reports from mobile operator network areas Messages with reports from mobile operator network areas are sent to all users in the mobile operator network, e.g. weather forecasts, traffic news, etc. Mode of receiving: to switch on/off the function for receiving reports from these areas. Read message: If this service is active, the particular type of message will appear on the display after switching on this function. Language: to select the language for receiving reports. Channel setting Select Add Edit Delete Note: After you switch the function on, you will receive reports from the area through SIM1. Call log Your phone can save a review of missed, dialled and received calls with the information about their length and eventually about their price. While connecting to the network, the list of missed and received calls can be downloaded (if this function is supported by the network). In the list, you can see the missed, dialled and received calls, you can display the length and date of the call, you can edit or delete a number in the list, you can save the number to the list, and you can have a look if the call was for SIM1 or SIM2. Missed calls: to view the list of thirty last missed calls (network service) with 20 missed calls for the SIM1 card and 10 missed calls for the SIM2 card. Note: When the phone displays the announcement about a missed call, press Read to open the list with further information. Mark the desired number and then dial it when pressing the call key for SIM1/SIM

28 Dialled calls: to view the list of thirty last outgoing calls. Received calls: to view the list of thirty last incoming calls. Delete call log: to delete call log of last calls saved on the SIM1 or SIM2 card. You can also select to delete all calls from SIM1 card which were saved within the last log (missed, outgoing and incoming calls from the SIM1 card). You can also select to delete all calls from the SIM2 card which were saved within the last log (missed, outgoing and incoming calls from the SIM2 card.). Call duration Last call duration: to view information about the length of the last call. Dialled altogether: to view information about the length of outgoing calls altogether. Received altogether: to view information about the length of incoming calls altogether. Reset all timers: to delete all counters of call length. Note: The length of call and the price charged by the operator for using services can be different. It depends on function settings in the network, taking into account the setting of the account, fax and other factors.. Price of calls: this function has to be supported by the mobile operator network. Price of last call: to view information about the price of the last call. Price altogether: to view information about the total price of calls. Reset prices: to delete all counters of call prices. Max.price: to set up maximum price per called units and per unit price. To activate the function for setting the maximum price per one call, enter PIN2. Price per unit: this function has to be supported by the mobile operator network, who can give you further information. Mode of call price: this function enables to set up the price to be charged per seconds or minutes. SMS counter for SIM1: to view the amount of sent and received SMS to the SIM1 card. It is possible to delete the content of the list within this function. SMS counter for SIM2: to view the amount of sent and received SMS to the SIM2 card. GPRS counter Last sent: to view the length of last sent data transfer within GPRS connection. Last received: to view the length of last received data transfer within GPRS connection. Sent altogether: to view the total length of sent data transfer within GPRS connection. Received altogether: to view the total length of received data transfer within GPRS connection. Reset counter: to delete all data in the transfer log

29 Profiles Your phone enables you to set a range of user profiles which you can use according to the situation and the environment where you are. First customize the profile according to your ideas and when needed use it then. Profiles you can use: General, Meeting, Outdoor, Indoor, Headset, Bluetooth and Standby. You can customize the following items in each profile: Tone settings: in this menu, you can set the following parameters: Incoming call, Alarm, Start-up tone, Switch-off tone, Message tone and Keypad tone. Volume: to set the volume for Ringing tone and Keypad tone. Type of alert: you can select from the following options Ringing, Vibration alert only, Vibration alert and ringing, Vibration alert and then ringing. Type of ringing: you can set Once, Repeatedly or Volume ascending. Extra tone: you can select from these options Alert, Fault, Connecting to the operator or Disconnecting. Mode of reply: if you switch on the possibility Any key, you can answer the call with any key. After finishing the setting of profile, switch on the option Activate. Note: If you connect the headset to the phone, the phone automatically switches to the Headset mode and the loudspeaker disconnects. The phone switches back to the mode General, when you disconnect the headset. To switch off sounds in the initial mode, press and hold #. To switch the sounds of the phone on, press and hold again. Services (only for SIM1) You can use a range of services available on the Internet. These functions can include information about the weather, news services, financial reports, etc. The possibility to use this service depends on the mobile operator network. If this function is possible, a new item appears in the menu of the SIM card. This function is not active, if the mobile network does not support it. To get more information, contact your mobile operator. WAP Homepage: connection to the address which is entered as homepage in settings. Bookmarks: you can use in the menu following functions, for operations with bookmarks: Go to: to go to the chosen address in the network. Edit: to edit the chosen bookmark or link to a network address. Delete: to delete chosen bookmark

30 Delete all: to delete bookmarks. Add bookmark: to add a new bookmark. Last web address: the list of 10 last opened addresses Enter address: to enter websites which you want to open. Incoming services: your phone can receive information sent by the service provider. Settings Edit profile Activate profile Edit profile Rename profile: to change the name of profile. Homepage: to enter a chosen address as homepage. Data account: to set the account in the network. Type of connection User name: to edit the user name Password: to edit the access password. Browser options: the possibility to set up the time limit and the way to view a picture. Service messages settings: on/off. Delete the cache: Too much data in the cache memory influences the speed of data transfer and displaying of information. Delete cookies: to delete cookies files. Trusted certificates: to view the list of saved certificates. Data account GSM: transfer data via GSM. GPRS: transfer data via GPRS. Note: About ordinary charged prices and specific settings of network, consult the representative of the mobile operator. For more information about these services ask the representative of the mobile operator

31 Settings Mode of SIM cards: you can set the following modes: Both SIM cards: setting of dual SIM mode. Without SIM cards: to disconnect from the network, when you are not allowed to use a mobile phone (e.g. on a aeroplane) or when you do not want to switch on any of the cards. Only SIM1 card: to switch to the mode Only SIM1. Only SIM2 card: to switch to the mode Only SIM2. Stylus calibration: if you think that the stylus makes inappropriate operations while you use it, make the new calibration on the touch screen. According to instructions, touch the mid-point of displayed cross. The announcement about successful calibration appears, after three right touches. Phone settings: in this menu you can set language, wallpaper on the surface, time and other features. Set the home town: to set the town where you are. Note: This setting should be used with an auto-update of time. If the operator network supports this function, the change of time and date will be done automatically. Set up time and date: to set the actual time and date. Set up the format: to set the format for displaying time and date. Note: If the battery has been removed from the phone or if the battery has been discharged any longer time before and has not been recharged, it will be necessary to set the time again when inserting the battery or recharging. Before coming to places where you are not allowed to use the mobile phone (e.g. aeroplanes), check that the device is switched off. In this way, possible accidents will be prevented. Planned switch on/off: to set the time when the device shall automatically switch on/off. Language: to set the language of the phone. Preferred method of text input: to set the way for data entering according to what you are used to. Display: Wallpaper Screen saver Display when switching on Display when switching off Display date and time Display own phone number Display operator name

32 Display missed calls Display missed SMS Welcome note: to set the welcoming text to be shown when the phone is switched on. Speed dialling: to set the function of speed dialling and editing of particular phone numbers. If the function is set, you can call selected phone numbers by pressing and holding the particular digit key in the initial mode of the device. Cursor key: to set the function for speed dialling key (Up, Down, Left and Right). Auto-update of date and time: If you want to edit and automatically set the actual time after coming into another time zone, switch this function on. It does not have any influence on the time set up for your home or office. This auto-update function can have an influence on selected vibration alerts. Without SIM cards: Normal Without SIM cards: Is the option Without SIM cards switched on, you can use the phone also in the aeroplane. Only functions of electronic organizer and multimedia player will be available. Ask when switching on Handwriting: to set features for entering data with writing. Handwriting style Speed of pen Colour of pen Other settings Illumination Call settings Identification of caller to SIM1: Set up by the network Hidden phone number: your phone number is not sent to the system. If the system does not support this function, it is possible that you can not connect to the server. Send phone number: sending of your phone number while dialling. Identification of caller to SIM2: Set up by the network Hidden phone number: your phone number is not sent to the system. If the system does not support this function, it is possible

33 that you can not connect to the server. Send phone number: sending of your phone number while dialling. Note: To use this function, it has to be supported by the mobile operator network. Waiting for calls to SIM1: you can switch this function on or off. Make sure, that this function is supported by the mobile operator network. Waiting for calls to SIM2: you can switch this function on or off. Make sure, that this function is supported by the mobile operator network. SIM1 call divert: You can use this function after it has been activated by the operator. The function enables you to divert a call to another phone number which you select. SIM2 call divert: You can use this function after it has been activated by the operator. This function enables you to divert a call to another phone number which you select. Function Description All calls Diverting of all incoming calls without any exception. Within the reach The network diverts calls, if it is not possible to connect to your phone. Not answered The network diverts calls, if you have not answered the phone for a particular time. Busy The network diverts calls, if you just have another call. All data calls Support of the network is required for diverting of data calls. Cancel all call diverts Cancelling of all set call diverts. Call Barring for SIM1 Outgoing calls Incoming calls Cancel all Change the barring password
