2 Our trash rack cleaning machines and hydro-mechanical equipment on Elbe and Vltava rivers in the Czech Republic

3 Čuňovo (Slovakia) Cleaning machine of trash racks at water turbine inlet Čuňovo Mošonský Dunaj Slovakia (1997) Type: Mobile hydraulic double-arm with local control. The trash is loaded into standard road container. 6,5 m 3,0 m Rake carrying capacity: 3000 kg

4 Gabčíkovo (Slovakia) Cleaning machine of trash racks at lock inlet Gabčíkovo Slovakia (1998) Type: Mobile rope cleaning machine, rake mechanics, electro-hydraulic system of lifting heavy objects from the depth of 30 m. The machine is fully automatic, computer controlled with remote control. 30 m 3,5 m Rake carrying capacity: 2000 kg

5 Kadaň Cleaning machine of trash racks at water turbine inlet Kadaň Ohře Czech Republic (2000) Type: Hydraulic double arms with fully automatic operation. The trash is loaded into standard road container. 14 m 7,0 m Rake carrying capacity: 800 kg

6 Bakov nad Jizerou Cleaning machine of trash racks at water turbine inlet Bakov nad Jizerou Czech Republic (2007) Type: Static, hydraulic double arms with fully automatic control from the power plant control panel. The trash is loaded on a belt conveyer. Rake carrying capacity: 5,0 m 6,3 m 600 kg

7 Hradišťko (Czech republic) Cleaning machine of trash racks at water turbine inlet Hradišťko Czech Republic (2007) Type: Mobile hydraulic double arm machine. Fully automatic, controlled by computer with remote control. Hydraulic lifting system is added to pickup heavy objects. Rake carrying capacity: 8,0 m 3,0 m 500 kg

8 Kostomlátky Cleaning machine of trash racks at water turbine inlet Kostomlátky Czech Republic (2007) Type: Mobile hydraulic double arm machine. Fully automatic controlled by computer with a remote control. Hydraulic lifting system is added to pick up objects up to 690 kg. Rake carrying capacity: 6,8 m 3,0 m 500 kg

9 Nubarriya (Egypt) Cleaning machine of trash racks at intake channel of pumping station Nubarriya Egypt (2007) Type: Mobile hydraulic double arm machine, fully automatic, controlled by computer. Hydraulic control of rake. Trash is lifted and loaded into a belt conveyer or container. Rake carrying capacity: 7,1 m 3,0 m 1000 kg

10 El Nour and Zaghloul (Egypt) Cleaning machine of trash racks at intake channel of pumping station El Nour and Zaghloul Egypt (2007) Type: Two mobile rope cleaning machines, full automatic control by computer, hydraulic rake opening and closing, rake pulled by a three-rope drum, trash is loaded into a tank with a shovel plate. Lift height: Lifting capacity: 5,3 m 1,8 m 1000 kg

11 Hučák Trash Rack Cleaning Machine at HPP Hučák, Czech Republic (2008) Type: Mobile hydraulic twin-arm with manual, semi-automatic and automatic control through a control panel or remotely from the HPP control center. The trash is picked up and loaded into a container. 4,7 m 3,4 m Load capacity: 500 kg

12 Spytihněv Trash Rack Cleaning Machine and mobile hydraulic lifting system at HPP Spytihněv, Czech Republic (2009) Type: Mobile hydraulic double arm machine, fully automatic, controlled by computer. Mobile hydraulic system is using to pickup heavy objects from the rough trash rack. Loading capacity: 350 kg / 5 m. The trash is picked up and loaded into a container. 5,7 m 3,5 m Load capacity: 500 kg

13 Předměřice Trash Rack Cleaning Machine and mobile hydraulic lifting system at HPP Předměřice Czech Republic (2009) Type: Mobile hydraulic double arm machine, fully automatic, controlled by computer. Mobile hydraulic system is using to pickup heavy objects from the rough trash rack. Loading capacity: 350 kg / 5 m. The trash is picked up and loaded into a container. Container is traveling on own rails. 5,5 m 3,0 m Load capacity: 500 kg

14 Miřejovice Trash Rack Cleaning Machine at HPP Miřejovice Czech Republic (2009) Type: Mobile hydraulic double arm machine with manual, semi-automatic and automatic control through a control panel or remotely from the HPP control center. The trash is loaded into a tank with a two-way traveling shovel plate. 7,0 m 2,5 m Load capacity: 500 kg

15 Nymburk Trash Rack Cleaning Machine at HPP Nymburk Czech Republic (2009) Type: Mobile hydraulic double arm machine, fully automatic, controlled by computer in a machine or from the HPP control center. The trash is picked up and loaded into a container. Container is traveling on own rails. Container is picked up on the truck with a standing derrick. Load capacity: 7,2 m 3,5 m 500 kg

16 Brno - Kníničky Illustration photo dam Kníničky Trash Rack Cleaning Machine at HPP Kníničky - Brno Czech Republic (2009) Type: Stationary rope cleaning machine with hydraulically operated rake, with semi-automatic and automatic control from the control panel or wireless from the HPP control room. The trash is digging into the container. Lift height: Lifting capacity: 18,1 m 4 m kg

17 Pardubice Trash Rack Cleaning Machine at HPP Pardubice Czech Republic (2009) Type: Stationary hydraulic twin-arm cleaning machine with manual, semi-automatic and automatic control through a control panel or remotely from the HPP control center. Hydraulic lifting system is added to pickup heavy objects. The trash is picked up and loaded into 2 containers. Load capacity: 8,5 m 6,2 m 500 kg

18 El Max (Egypt) Cleaning machine of trash racks at intake channel of pumping station El Max Egypt (2010) Type: Mobile hydraulic double arm machine, fully automatic, controlled by computer. Arms and rake of stainlles steel. Rake carrying capacity: Rail way: Belt conveyers: 4,8 m 3,0 m 1000 kg 30 m 45 m

19 Tři Chaloupky Trash Rack Cleaning Machine at HPP Tři Chaloupky Czech Republic (2010) Type: Stationary hydraulic twin-arm cleaning machine with manual, semi-automatic and automatic control through a control panel or remotely from the HPP control center. The trash is lifted and loaded into a belt conveyer and then into standard road container. Load capacity: 7,6 m 11,3 m 1200 kg

20 Brno - Komín Trash Rack Cleaning Machine at HPP Komín - Brno Czech Republic (2011) Type: Mobile hydraulic double arm machine, fully automatic, controlled by computer in a machine or from the HPP control center. The trash is picked up and loaded into a container. A self-standing hydraulic hand is used to lift heavy objects. 5,5 m 3,0 m Load capacity: 500 kg

21 Myší Vršok (Slovenská republika) Trash Rack Cleaning Machine at HPP Myší Vŕšok Slovak Republic (2011) Type: Stationary one-arm hydraulic-mechanical cleaning machine. Movement of the pull-out arm is mechanically secured by a transmission with a chain, the pressure of the rake is then hydraulically. The machine was supplied with remote control via SMS. The trash is picked up into standard road container. 4,8 m 2,8 m Load capacity: 250 kg

22 Lobkovice Trash Rack Cleaning Machine at HPP Lobkovice, Czech Republic (2011) Type: Stationary hydraulic double arm machine with manual, semi-automatic and automatic control through a control panel or remotely from the HPP control center. The trash is picked up and loaded into a container. 5,6 m 2,7 m Load capacity: 500 kg

23 Vrané nad Vltavou Coarse racks cleaning machine at HPP Vrané nad Vltavou Czech Republic (2011) Type: Cleaning machine is located on the gantry of the inlet channel to HPP Vrané nad Vltavou (ČEZ a.s.). The 14 tons machine is equipped with a HIAB hydraulic arm. The mobile hydraulic arm is controlled by the remote control. Trash from coarse racks are picked up in a standard road container located on a trailer towed behind the machine. 11,0 m 73 m Load capacity: 1,0 t / 5 m

24 Smiřice Trash Rack Cleaning Machine and mobile hydraulic lifting system at HPP Smiřice Czech Republic (2012) Type: Mobile hydraulic double arm machine, fully automatic, controlled by computer. The trash is loaded into a stainless steel tank with a two-way traveling shovel plate. The machine runs on a curved rails. Mobile hydraulic system is using to pickup heavy objects from the rough trash rack. Loading capacity: 350 kg / 5 m. 6,3 m 3 m Load capacity: 500 kg

25 Velký Osek Trash Rack Cleaning Machine at HPP Velký Osek Czech Republic (2012) Type: Mobile hydraulic double arm machine with hydraulic tilting container. Fully automatic, controlled by computer. The trash is picked up and loaded into a container. Load capacity: 8,6 m 3,8 m 500 kg

26 Al Shabab (Egypt) The photos are from the test assembly of the machine in the Czech Republic Cleaning machine of trash racks at intake channel of pumping station Al Shabab - Egypt (2012) Type: Mobile hydraulic double arm machine, fully automatic, controlled by computer. The trash is picked up and loaded into a container. Load capacity: 3,8 m 1,6 m 500 kg

27 Rankina (Romania) Trash Rack Cleaning Machines at HPP Rankina Romania (2012) Type: Stationary hydraulic double arm machine, fully automatic, remotely from the HPP control center. The trash is lifted and loaded into a belt conveyer. 4,1 m 5,6 m Load capacity: 500 kg

28 Litoměřice Trash Rack Cleaning Machine at HPP Litoměřice Czech Republic (2012) Type: Mobile rope cleaning machine with a crane with lifting capacity of 15 tons for handling with a stop logs. Machine is equipped by hydraulic arm with load capacity of 5 tm. The machine, which runs on rails of 34 m, is fully automatic, controlled by a computer with a remote control. Lift height: 20,3 m 3,5 m Lifting capacity: kg

29 Borek Szlachecki (Poland) The first photo is from the test assembly of the machine in the Czech Republic Trash Rack Cleaning Machine at HPP Borek Szlachecki Poland (2013) Type: Hydraulic, double arm, stationary cleaning machine. Is provided with a rotatable container of ,4 m 3,5 m Load capacity: 500 kg

30 Soběnov Trash Rack Cleaning Machine at HPP Soběnov Czech Republic (2013) Type: Stationary, hydraulic, double arm cleaning machine with fixed container. Machine is fully automatic, controlled by computer or remotely from the HPP control center. Load capacity: 5,6 m 4,6 m 500 kg

31 Písek Trash Rack Cleaning Machine at HPP Písek Czech Republic (2013) Type: Mobile hydraulic double-arm cleaning machine with carried container. Fully automatic, controlled by computer with remote control. Removing the container from the machine is ensured by a stationary hydraulic arm. 4,5 m 3,4 m Rake carrying capacity: 500 kg

32 Liběchov Trash rack cleaning machine of water turbines inlet HPP Liběchov Czech Republic (2013) Type: Supply and installation of mobile rope cleaning machine with container winched on truck, and upper and lower sluice valves. Lift height: Lifting capacity: 17,2 m 4,6 m kg

33 Číčová Trash rack cleaning machine of water turbines inlet HPP Číčová Czech Republic (2013) Type: Supply and installation of complete technology for HPP with two turbines 3Th 750 with output 2x37 kw with head 2,89 m and flow 4,2 m3/s with static hydraulic telescopic cleaning machine. 3 m 4,5 m Rake carrying capacity: 250 kg

34 Štětí Trash rack cleaning machine of water turbines inlet HPP Štětí Czech Republic (2014) Type: Mobile rope cleaning machine equipped with a crane of capacity of 15 t for handling sluice gates and also with hydraulic hand of capacity of 5 tm for lifting heavy objects. Machine travels on a rail track of length of 34 m. Fully automatic, controlled by a computer with a remote control. Lift height: 20,5 m 3,5 m Lifting capacity: kg

35 Štěchovice Coarse trash rack cleaning machine HPP Štěchovice Czech Republic (2014) Type: Coarse trash rack cleaning machine equipped with hydraulic arm is moving on railway. Local and remote control. Carrying capacity: Railway: 10 m kg 37 m

36 Čergov (Slovakia) Cleaning machines of trash racks at intake channel of pumping station Čergov Slovakia (2015) Type: 3 static, hydraulic double arms with fully automatic control from the power plant control panel. The trash is loaded on a belt conveyer. Rake carrying capacity: 4 m 5 m 500 kg

37 Veletov Trash rack cleaning machine of water turbines inlet SHPP Veletov Czech Republic (2016) Type: Static, hydraulic, telescopic machine with belt conveyer. Remote control via the Internet. Swinging rake at the level of trash racks. 3 m 4 m Rake capacity: 250 kg
