1 strojlab another world David Palousek Ústav konstruování Fakulta strojního inženýrství VUT v Brně

2 Outlines 1. What is FabLab? 2. FabLabs and Czech republic 3. FabLabs and Brno 4. Exmaples 5. strojlab and FME BUT Brno 6. FabLabNet 2/45

3 Fablab (fabrication laboratories) Wikipedia: A fab lab (fabrication laboratory) is a small-scale workshop offering (personal) digital fabrication. History - Collaboration between the Grassroots Invention Group and the Center for Bits and Atoms at the Media Lab in the Massachusetts Institute of Technology - Neil Gershenfeld, profesor na MIT - The fab lab movement is closely aligned with the DIY, the open source hardware and the free and open source movement, and shares philosophy as also technology with them 3/45

4 Fablab ( A Fab Lab is a technical prototyping platform for innovation and invention, providing stimulus for local entrepreneurship. A Fab Lab is also a platform for learning and innovation: a place to play, to create, to learn, to mentor, to invent. 4/45

5 Maker Movement - People employing do-it-yourself (DIY) and do-it-with-others ( DIWO) - DIY and DIWO enables individuals to create sophisticated device - Digital technologies - Manual workshops - Own market ecosystem 5/45

6 Fablab ( 6/45

7 Fablab ( 7/45

8 Fablab (fabrication laboratories) Czech republic, Slovak Republic (except Brno) - Brmlab hackerspace (Praha) - DEPO2015 (Plzen) creative area (makerspace, coworking, incubators) - Paralelní Polis (Praha) - MakerPoint (Ústi nad Labem) - Fajna dílna (První otevřená dílna pro veřejnost v Ostravě) - FabLab Bratislava (Slovak Republic) 8/45

9 DEPO2015 (Plzen) creative area (makerspace, coworking, incubator) 9/45

10 Paralelní Polis FabLabNet - strojlab 10/45

11 Paralelní Polis FabLabNet - strojlab 11/45

12 Paralelní Polis FabLabNet - strojlab 12/45

13 Fablab (fabrication laboratories) Brno, Czech republic, Slovak Republic - FabLab Brno (JIC) - strojlab (FSI VUT) - Industra (Masná) - Hobbylab (Holzova, Líšeň) - Rebelion: otevřená šicí dílna - Brno šije: sdílená šicí dílna - Robotárna 13/45

14 Equipment FabLabNet - strojlab 14/45

15 MUSE 15/45

16 Fremont Lab - off-campus facility University of Washington /fremont-fab-lab 16/45

17 FabLab Graz Laboratory of the Institute of Innovation and Industrial Management (IIM) at Graz University of Technology 17/45

18 FabLab ZURICH 18/45

19 FabLab Budapest 19/45

20 Mobile Fab Lab 20/45

21 Laboratoře otevřené studentským projektům 21/45

22 22/45

23 23/45

24 strojlab Proč podporovat myšlenku fablabu na univerzitě? (Why to support FabLab idea?) - Podpora nefrontální formy výuky (non-frontal education system) - Podpora semestrálních projektů (semestral projects support) - Podpora BP a DP (bachelor and diploma thesis support) - Získání talentovaných studentů (talented students searching) - Budování komunity (community support) - PR a propagace (public relations) 24/45

25 strojlab new entry system 25/45

26 RepRap Dreamer - Dvoutrysková tiskárna (dual nozzle) - Různé materiály (materials ABS, PLA, ASA, HIPS...) - Plocha tisku 230x150x140 mm (platform 230x150x140mm) - Jednoduchost přípravy a ovládání (easy to use and control) - FlashPrint software 26/45

27 RepRap UK printer - Vlastní vývoj (testing 3D printer) - Speciální parametry (special materials, ULTEM, PC) - Výhřev komory 200 C (heating systém up to 200 C) 27/45

28 Profesionální tiskárny (professional 3D printers) Dimension SST 1200 ABS, vysoká kvalita 3D tisku (high quality of parts) Parametry zařízení Dimension sst 1200es: Velikost pracovního prostoru: 250 x 250 x 300 mm (platform dimensions: 250 x 250 x 300 mm) Materiál: ABS Tloušťka vrstvy: 0,25 mm a 0,33mm Podpůrné struktury: ANO Post-processing: není nutný, barvení, otryskávaní 28/45

29 Profesionální tiskárny (Professional 3D printers) Dimension Elite ABS, vysoká kvalita 3D tisku (high quality) Parametry zařízení Dimension Elite (parameters): Velikost pracovního prostoru: 200x200x300 mm (platform dimensions) Materiál: ABS Tloušťka vrstvy: 0,18 a 0,25 mm (layer thickness) Podpůrné struktury: ANO (support structures yes) Post-processing: není nutný, barvení, otryskávání (post-processing: coloring, blasting) 29/45

30 Vakuové lisování (vacuum forming) Formec Forming area: 622mm x 622mm Depth of draw: 400mm Max material thickness: 6mm PET-G, PP 30/45

31 Profesionální tiskárny (professional 3D printers) Zprinter 650 Sádrokompozitní plnobarevný 3D tisk (plastercomposite full-color 3D printing) Parametry zařízení (parameters of equipment): 254 x 381 x 203 mm Sádro-kompozitní prášek (Plaster-composite powder) Tloušťka vrstvy (layer thickness): 0,089-0,102 mm Post-processing: solný roztok, nízko-viskózní vosk, originální Zbond (saline, Low-viscous wax, resin, cyanoacrylate) 31/45

32 KUKA robot Obrábění (Milling) 3D tisk (3Dprinting) Automatizace digitalizace (automatic digitization) 32/45

33 3D optický skener (3D optical scanners) 33/45

34 Partneři projektu FabLabNet (project partners) Jihomoravské inovační centrum (South Moravian innovation center) Computer agency o.p.s. MUSE - Science museum FABRICATION LABORATORY LTD. ROGLAB Museum and galleries of Ljubljana FABLAB, Association for Promoting Digital Fabrication INNOC Austrian Society for Innovation Computer Science URBAN LAB nonprofit company Regional development agency in Bielsko-Biala Slovak Scientific and Technical Information Centre 34/45

35 Benefits FabLabNet aims to foster international networks and links both with schools and businesses. The project joins a number of fablabs into a central European network: 9 project partners - inspired by and strictly connected to 11 associated partners - share experiences and develop activities to boost their knowledge and capacity, following trends set by the European movement that emphasizes new business models, and marks the difference in current cultural & business world. While local Smart Specialization Strategies (local S3) are the starting point to determine the distinctive features of each single fablab, the project objective is to uncover & share effective technical & organizational resources among the network, to develop innovative services for local communities, business and educational institutions and to set up and fine tune efficient communication. Pilot activities, both at national and transnational level, help the project to root & spread its well assessed knowledge, practices and capacities in a European horizon, a framework that connects the world of fablabs with a fully developed, advanced business field. 35/45

36 Benefits for Institute of Machine and Industrial Design (outcomes) 1. Tutorials a guides for DIY (digital technologies, electronic, measurements) 2. Equipment (3D printers, electronics, boards, hardware, ) 3. Background for project base learning system 4. Involve bachelors 5. Community building 6. Brand awareness 36/45

37 How it will work? RepRaps (Dreamer, Delta), electronic Stratasys Vaccum forming Zprinter 650 KUKA 3D scanner ATOS Level 1 Level 2 Level 3 Master b b b b b b b b b b b b b b b b 37/45

38 New enthusiasts Strojvedoucí (Train drivers): Josef Březina Questions 1. Who will lead strojlab after the end of the project? 2. Fees Y/N? 3. How to pay a repairs? 4. How to control participants? 5. Reliance 38/45

39 FabLab innovation ekosystém + Autodesk Academia /45

40 Public relation Autodesk Academia Design /45

41 Public relation Autodesk Academia Design /45

42 Public relation Autodesk Academia Design /45

43 Public relation Autodesk Academia Design 2017 Czech Radio Plus 43/45

44 Public relation /45

45 /45

46 David Paloušek Ústav konstruování NETME Centre 3Dlaboratory.cz /45
