HP networking aneb pojďme vytvářet spolehlivé, chytré a výkonné sítě s doživotní zárukou a jednotným managementem

Transkript

1 HP networking aneb pojďme vytvářet spolehlivé, chytré a výkonné sítě s doživotní zárukou a jednotným managementem Daniel Fertšák Solution architect daniel.fertsak@hp.com 2011 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice

2 Agenda HP Networking úvod Virtualizace LAN pomocí IRF popis a nasazení WLAN architektura IMC nástroj pro management sítí

3 Trendy v dnešních sítích? Závislost služeb na síti Narůstající nároky aplikací Virtualizace Přílišná složitost Stárnutí infrastruktury Správa, TCO 3 Méně jak 30% IT rozpočtu směřuje do oblasti inovací

4 HP FlexNetwork architecture Od datového centra, přes campus k pobočkám a správě FlexFabric FlexCampus FlexBranch Výkonné a spolehlivé datove centrum Drátové a bezdrátové technologie pod jednou střechou Síťové prostředky s aplikacemi na pobočkách Otevřená Škálovatelná Bezpečná Akceschopná Konzistentní

5 HPN portfolio ADVANCED ESSENTIAL VALUE SECURITY Modular Switches HP A12500 HP A10500 HP A9500 HP A7500 Top of Rack Switches HP A5810 HP A5820 HP A5830 Server Blade Switch HP A6120 Modular Switches HP E8200 HP E5400 HP E4200 Fixed Port Switches HP E6600XG HP 6200yl HP E3800 HP E3500yl HP E2910al HP E25x0G HP E3500 HP E26x0 HP E25x0 Web Managed Switches HP V19x0 HP V1810 HP V1700 Unmanaged Switches HP V14x0 WLAN HP M200 AP IPS HP S6100N HP S5100N HP S2500N HP S1400N HP S660N HP S330 HP S110 HP S10 HP Core Controller Management SMS HP SMS Controller Fixed Port Switches WLAN HP A5800 HP A5500 HP A5120 HP A36x0 HP A3100 Routers HP A8800 HP A6600 HP A-MSR 50 HP A-MSR 30 HP A-MSR 20 HP A-MSR 900 WLAN HP A-WX5004 Controller HP A-WA2xxx Access Points HP A3000 Wireless Switches HP A9000 Access Points HP A8760 Access Point HP A7760 Access Point Management HP E-MSM7xx Controllers HP E-MSM4xx Access Points HP E-MSM3xx Access Points HP E-M110 Access Point HP E-MSM317 Access Point Unified Communications HP UC Applications HP 41xx IP Phones Management PCM/PCM+ IDM NIM TMS zl Module Advanced: For customers with large/complex deployments seeking advanced, full featured networking technology to drive competitive advantage with lower cost of ownership. Essential: For customers seeking essential proven technology that s affordable and easy to use while providing scalability for future needs. Value: For value-conscious customers seeking reliable and easy-to-use connectivity solutions. IMC NNMi NA

6 Topologie enterprise sitě a nemohlo by to být jednoduší? REMOTE SP1 Internet SP2 VPN WAN Access Internet Access DMZ CORE Distribution Management ACCESS Campus Data Center

7 Design s využitim IRF Core/Distribution Access Active/Active Management pohled Scalable Server Bandwidth All links are active. + Simplified/virtualized L2/L3 design and operations with a single IP and configuration file. No need for STP neither for VRRP. No MSTP design and operations headache. Switching and routing functions get virtualized as well as service modules. + Allows multiple active paths for scalable performance + Near instantaneous network recovery ensures business continuity and superior user experience

8 IRF flexibilita, výkon, jednoduchost Technologie virtualizace sítě Wiring closet or ToR Horizontální stacking přes rozvaděče nebo racky Ideální do campusu i datového centra lokálně i přes geografické oblasti Až 9 zařízení Podporuje i 70 km up to 9 in an IRF stack - Od datového centra přes páteř a agregaci až k přístupové vrstvě - Patrové rozvaděče, top of rack, core switche - Kompletní virtualizace (virtuální chassis) na L2 i L3, méně konfiguračních souborů a protokolů - Přes lokální kabely i optikou přes rozdílné lokality - Rapid failover, ISSU, MAD,...

9 PWR SYS ESM H3C MSR Řešení pro malou firmu - redundantní 3G internet HP MSR IRF Stack Internet HP SFP 1Gb/s 1Gb/s HP SFP 100Mb/s 100Mb/s 100Mb/s HP 3100 EI HP 3100 EI HP 3100 EI 10 HP CONFIDENTIAL For HP and Channel Partners Internal Use Only 5/31/2012

10 Power Fault Locator ProCurve Switch 5406zl J8699A PoE HP E5406 zl Switch J9533A A ProCurve 24p Gig-T zl Module J8702A HP Gig-T PoE+ v2 zl Mod J9534A C E HP Innovation PoE-Integrated PoE+ 10/100/1000Base-T Ports Ports (1-24) (1-24) - Ports - Ports are are IEEE Auto-MDIX MDI/MDI-X Use zl Modules only Module B ProCurve 24p Gig-T zl Module J8702A HP Gig-T/SFP+ v2 zl Mod J9536A D F HP E5400 zl Switch Management Module J8726A ProCurve Switch 5400zl Management Module J8726A Reset Clear 4 Test Mgmt Flash Chas DIMM 6 6 PoE Temp Fan Status 4 2 Internal Power PoE Pwr A C E B D F CF G I K Modules DO NOT REMOVE DURING LED FLASHING PoE-Integrated PoE+ Integrated 10/100/1000Base-T Ports Ports (1-24) (1-20) - Ports - Ports are IEEE are Auto-MDIX MDI/MDI-X H J L 14 Act FDx Spd LED Mode 16 PoE Usr CF CARD Console Auxiliary Port 24 Use only supported transceivers CONSOLE AUX Module PWR SYS USB0 Power Fault Locator ProCurve Switch 5406zl J8699A PoE HP E5406 zl Switch J9533A A ProCurve 24p Gig-T zl Module J8702A HP Gig-T PoE+ v2 zl Mod J9534A C E ~ V 50/60Hz;3.5A H3C MSR ON 4 4 OFF HP Innovation PoE-Integrated PoE+ 10/100/1000Base-T Ports Ports (1-24) (1-24) - Ports - Ports are are IEEE Auto-MDIX MDI/MDI-X Use zl Modules only Module B ProCurve 24p Gig-T zl Module J8702A HP Gig-T/SFP+ v2 zl Mod J9536A D F HP E5400 zl Switch Management Module J8726A ProCurve Switch 5400zl Management Module J8726A Reset Clear 4 Test Mgmt Flash Chas DIMM 6 6 PoE Temp Fan Status 4 2 Internal Power PoE Pwr A C E B D F G I K Modules PoE-Integrated PoE+ Integrated 10/100/1000Base-T Ports Ports (1-24) (1-20) - Ports - Ports are IEEE are Auto-MDIX MDI/MDI-X H J L 14 Act FDx Spd LED Mode 16 PoE Usr Console Auxiliary Port 24 Use only supported transceivers Module Řešení pro střední firmu s vizí budoucího rozvoje Internet #2 HP MSR30-40 Internet #1 ProCurve Networking ProCurve Networking zl zl 22 zl 1-GbE/10-GbE SFP+ Ports zl zl zl 22 zl 1-GbE/10-GbE SFP+ Ports zl HP 5406zl 1GE HP 5406zl 10GE HP 5120 EI HP 5120 EI HP 5120 EI HP 5120 EI 11 HP CONFIDENTIAL For HP and Channel Partners Internal Use Only 5/31/2012

11 Řešení pro enterprise wirespeed 10 GbE páteř Internet #2 HP 6604 Internet #1 HP IRF HP GE 10GE HP 5120 EI IRF HP 5120 EI HP 5120 EI HP 5120 EI 12 HP CONFIDENTIAL For HP and Channel Partners Internal Use Only 5/31/2012

12 Redundatní 10GE připojení serverů v datovém centru 10GbE 10GbE HP 5920AF 10GbE HP 5920AF 13 HP CONFIDENTIAL For HP and Channel Partners Internal Use Only 5/31/2012

13 HP 5900AF 10GE ToR switch pro DC Konvergence dat, výpočetních prostředků a storage Vysoká hustota 10G portů (až 60 na 1U) 40 GE porty, konverze 40GE na 4x10 GE předo-zadní chlazení, zado-přední chlazení 48x 1G/10GBaseX SFP+ 4 * 40GbE QSFP IRF technologie pro virtualizaci prvků Funkční výbava L2/L3 a IPv4/IPv6 dual stack DCB podpora pro konvergované řešení Připraveno na TRILL, VEPA, FCoE

14 HP GE ToR switch pro DC Konvergence dat, výpočetních prostředků a storage 24x 10G SFP + portů IRF technologie pro virtualizaci prvků (max. 4) 480Gbps switch capability, Mpps forwarding throughput deep packet buffering (3.6 GB) + 9 MB interní buffer předo-zadní chlazení, zado-přední chlazení cut-throw a nízká latence FRONT TO BACK BACK TO FRONT

15 Comware verze 7 nový software kompletně nový kód - linux based aktuálně pro DC a metro ethernet vylepšená izolace procesů/úloh feature set - fáze I/II identické CLI jako CMW5 Single box hitless upgrade přepínače s cmw7 5900/ For HP Internal and Partner Use Only NDA until August 29

16 HP 5800AF 1GE ToR switch pro DC Řada 58xx optimalizovaná pro datová centra 48x1GE 6x10G SFP+ portů Modely s předo-zadním chlazením Redundantí duální napájení Modely s MPLS/VPLS TOP OF RACK END OF ROW Podpora IRF (max. 9), mix IRF s 5820AF

17 HP 5500-HI pro přístupovou i agregační vrstvu 1GE wirespeed L3 přepínač, 24/48 portů 2 přední10ge SFP+ porty, 4xSFP, OOB mgmt 2 rošiřující sloty (max. 58x1GE, 6x10GE) Duální napájení, EEE (IEEE 802.3az) RIP, OSFP, ISIS, BGP, MPLS, VPLS, IRF (max.9) Dual boot-rom, Dual core In hardware OAM, CFD doživotní záruka

18 HP 3600v2 & 3100v2 100 Mb refresh hardware refresh upgrade CPU a RAM comware verze 5 dvě verze firmware SI/EI 3100 v2 verze bez ventilátorů 3100 Layer 2, 3600 Layer 3 Vylepšení: IRF, SFLOW, Egress ACL, PoE+ doživotní záruka PVSTP+, PVLAN, IPv6, SAVI 3600 v2

19 Vlajková loď HP s CLOS architekturou wire speed 10 GbE, 160G per slot IRF dává G portů v jednom systému Latence 3 mikrosekundy 40 GbE, 100 GbE ready 4 chassis v IRF Nové line karty: 4x40GE, 48x10GE Nové sw. fabriky B,D (320/480G per slot)

20 WLANs: frequency spectrum of operation Unlicensed bands 83.5 MHz 675 MHz 2,4 GHz 5 GHz 2.4 GHz GHz 5.15 GHz GHz b/g (54 Mb/s) n a n (300 Mb/s)

21 Beamforming 22

22 Local Mesh Local Mesh extends wireless to areas where Ethernet is not available Inside hotels, factories, hospitals, outdoor campus, LAN bridge between buildings Self-healing links, self-optimizing links, multiple egress gateways Multiple configuration options for wireless access and backhaul Extension of wireless coverage through local mesh Wireless Links Wireless Links Connecting wired networks over local mesh Wireless Links

23 Wireless Infrastructure Models (1) Autonomous Architecture Controller-based WLAN Architecture PoE Switch MSM Controller Core or Aggregation Switch Access Switch Access Points Access Points 24

24 Wireless Infrastructure Models (2) Centralized Access Control Distributed Forwarding Distributed Forwarding with Centralized Authentication MSM Controller Corporate Network MSM Controller Corporate Network MSM Controller Corporate Network Access Switch Access Switch Access Switch Access Points Access Points Access Points Authentication Traffic User Traffic 25

25 E Series Wireless LAN Portfolio Wireless Application Wireless Controller HP ProCurve Manager Plus + HP Mobility Manager Multiservice Controllers Multiservice Controller Module MSM710 Mobility Controller MSM760 Mobility Controller MSM720 Mobility Controller MSM765zl Mobility Controller Wireless Access Point Indoor APs Sensor APs Outdoor APs Special Purpose AP MSM430 N Dual Radio MSM310 A/B/G Single Radio MSM410 N Single Radio MSM325 A/B/G Dual Radio MSM335 A/B/G Triple Radio MSM466/460 N Dual Radio 3 MSM320 Spatial Streams A/B/G Dual Radio MSM422 A/B/G & N Dual Radio MSM415 A/B/G & N Dual radio Dedicated Sensor MSM466-R A/B/G/N Du al Radio NEMA 4x rated MSM317 Access Device

26 MSM720 Wireless Controller Network capacity starts at 10 APs and is upgradeable to 40 APs complimenting MSM710 (up to 10 APs) and MSM760/765 (40 to 200 APs) High performance, scalable MSM controller offers flexible physical configuration options 4 RJ45 Gigabit ports (non-poe) and 2 dual personality G ports fully under software control RJ-45 Console port IEEE 802.3ad Link Aggregation Control Protocol (LACP) support Supports an optional Premium Mobility Package Supports G chassis mounting options Two models (WW and TAA versions) Delivering the best ease of use, flexibility & lowest TCO for10-40 AP configurations HP MSM720 Access Controller HP MSM720 Premium Mobility Controller Lifetime warranty on hardware Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice

27 Packaging: Advanced Features by Platform Capability MSM710/720/760 Access Controller MSM710 Mobility Controller or Mobility Services Upgrade MSM720/60 Premium Mobility Controller or Premium Mobility Upgrade Roaming MSM765 Premium Mobility Controller Layer 2 Mobility Supports data and voice clients. WPA2 Opportunistic Key caching Layer 3 Mobility Resiliency and Scalability Notes Opportunistic key caching enables seamless roaming in WPA2-Enterprise deployments Enables seamless L3 roaming via Mobility Traffic Manager (MTM) or subnet-based roaming. N+1 Resiliency For high availability support Controller Teaming Maximum of two (2) MSM720 with a single point of management for up to 40 APs/team in an N+1 configuration. Maximum of five (5) MSM76x with a single point of management for up to 800 APs/team in an N+1 configuration; Team must consist of same type of controller i.e., all MSM760s or all MSM765s) VSCs Supported Enhanced scalability for MSM720/76x controllers Concurrent Guest Access Users 100 (MSM710) 250 (MSM720) 2000 (MSM76x) Limits are unrelated to AP licensing (v5.7 and later) 28

28 Scalability: Virtual Controller Failover (MSM76x) 800 active APs (maximum allowed) equally configured across all controllers L2 Network Virtual Controller Team Manager Member Member Member Member MSM AP License MSM AP License MSM AP License MSM AP License MSM AP License 2011 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice

29 Scalability: Virtual Controller Failover (MSM76x) Virtual Controller 800 active APs (maximum allowed) equally configured across all controllers L2 Network Team Manager Member Failure MSM AP License MSM AP License 40 APs failover to this controller 40 APs failover to this controller Member MSM AP License 40 APs failover to this controller Member 160 APs failover without rebooting Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice MSM AP License 40 APs failover to this controller

30 802.11n Access Point Positioning Feature MSM466-R MSM466 MSM460 MSM430 MSM410 Dual n radios Yes Yes Yes Yes No IEEE 802.3af PoE Yes Yes Yes Yes Yes High-performance Dual core processors Number of transmitters/ receivers Number of spatial streams Yes Yes Yes Yes No 3x3 3x3 3x3 3x3 3x Max performance 450 Mbps/radio 450 Mbps/radio 450 Mbps/radio 300 Mbps/radio 300 Mbps/radio Antenna External External Internal Internal Internal Concurrent 5GHz support Yes Yes No No No Lifetime warranty 1 year Yes Yes Yes Yes List price $ $ $ $ $

31 MSM466-R Delivering the highest performing dual radio n outdoor AP MSM466-R AP feature set Powered by 802.3af or 802.3at PoE* AP, Mesh and Monitor (packet capture) modes Six N Type Connectors Flexible pole and wall mounting options Environmental design features IP67 and NEMA 4X rated, providing protection against water intrusion and salt fog damage Waterproof Ethernet PoE connector kit Reset to Factory button LEDs for visual indication of unit health Power, LAN, Radio 1, Radio 2-40 C* to 55 C operating temperature Embedded heater * Operation under -20 C requires 802.3at PoE 32

32 Centrální správa HP imc automatizuje síť a udržuje ji v dobré kondici Zálohování a audit konfigurací Vizualizace sítě i vlastního datového centra Vyhledávání serverů a zařízení Monitoring výkonu Správa sítí ve VMware, Hyper-V i Virtual Connect Možnost vzdáleného přístupu z Android či ipad 33

33 imc a portfolio modulů HP Intelligent Management Center framework FCAPS Model Fault Configuration Accounting Performance Security IMC Platform Features Alarms Syslog & Trap Manager Intelligent Configuration Center QoS/SL A Manager VLAN & ACL Manager Network Assets Performance Mgmt Virtual Network Mgmt Security Control Center Add-On Modules Service Operation Mgmt IPSec VPN Manager MPLS VPN Manager Wireless Services Manager User Behavior Analysis Desktop Asset Mgmt Network Traffic Analyzer User Access Manager Endpoint Admissio n Defense

34 Výzkum společnost Gartner o dual-vendor strategii Introducing a second vendor into the network infrastructure will have no long-term impact on operational costs for organizations following best practices. Introducing a second networking vendor will reduce total cost of ownership (TCO) for most organizations by at least 15% to 25% over a five-year time frame. We did not encounter one example where operational cost savings would offset the equipment cost premium that Cisco generally charges. Most organizations that introduced a second vendor report a lasting decrease in network complexity, compared with an all-cisco network. Network operations teams that are already using some form of multivendor management tools for fault alerting, configuration management or performance management are wellpositioned to take advantage of the second-vendor opportunity 35

35 HP a podpora multi-vendor zákazníků Standardy a testování interoperability Proof of concept se začleněním do stávající sítě Integrační dokumenty modelové příklady, srovnání konfiguračních kroků a konkrétních příkazů Školení interoperability zaměřené na konfiguraci HP/Cisco prostředí imc management sítě s podporou 220 výrobců Orchestrační nástroje pro celé IT s multi-vendor podporou Akcelerované vzdělávací programy pro Cisco certifikované techniky

36 HP NETWORKING Široké portfolio produktů (SMB i Enterprise) Nižší TCO (záruky, spotřeba, licence, správa, otevřenost,...) Pokročilá inovativní architektura (IRF, distribuovaný forwarding) Jednotný management HP i Cisco sítě (imc)
